| 단위 UNIT : m/m |
기호
SPECIF
형식
MODEL |
Ma
(kgf-m) |
M
(fgf-m) |
β(˚) |
dØH7 |
DØ |
L |
L1 |
C |
ℓ |
AxBJS9 |
M |
(g) |
| KD-6 |
- |
0.8 |
1.6 |
30 |
6 |
12 |
55 |
16.5 |
22 |
10 |
- |
- |
0.038 |
| KD-8 |
- |
1.5 |
3.2 |
30 |
8 |
16 |
65 |
20.0 |
25 |
11 |
- |
- |
0.090 |
| KD-10 |
KD-10KD |
3.0 |
7.5 |
30 |
10 |
20 |
71 |
22.5 |
26 |
13 |
3×11.8 |
M5 |
0.120 |
| KD-12 |
KD-12KD |
4.5 |
12.0 |
30 |
12 |
24 |
83 |
25.5 |
32 |
14 |
4×13.8 |
M5 |
0.200 |
| KD-14 |
KD-14KD |
7.0 |
17.0 |
30 |
14 |
28 |
98 |
30.5 |
37 |
17 |
5×16.3 |
M6 |
0.310 |
| KD-16 |
KD-16KD |
10.0 |
25.0 |
30 |
16 |
32 |
113 |
34.5 |
44 |
19 |
5×18.3 |
M6 |
0.470 |
| KD-18 |
KD-18KD |
13.0 |
32.0 |
30 |
18 |
36 |
126 |
38.5 |
49 |
21 |
6×20.8 |
M6 |
0.650 |
| KD-20 |
KD-20KD |
18.0 |
45.0 |
30 |
20 |
40 |
141 |
43.5 |
54 |
24 |
6×22.8 |
M6 |
0.950 |
| KD-22 |
KD-22KD |
24.0 |
60.0 |
30 |
22 |
44 |
154 |
47.5 |
59 |
26 |
6×24.8 |
M6 |
1.20 |
| KD-25 |
KD-25KD |
30.0 |
80.0 |
30 |
25 |
50 |
180 |
55.5 |
69 |
30 |
8×28.3 |
M8 |
1.80 |
| KD-30 |
KD-30KD |
45.0 |
115.0 |
30 |
30 |
60 |
207 |
65.0 |
77 |
37 |
8×33.3 |
M8 |
3.00 |
| KD-35 |
KD-35KD |
55.0 |
180.0 |
30 |
35 |
70 |
240 |
74.5 |
91 |
41 |
10×38.3 |
M8 |
4.70 |
| KD-40 |
KD-40KD |
85.0 |
250.0 |
30 |
40 |
80 |
269 |
83.5 |
102 |
46 |
12×43.3 |
M10 |
7.50 |
| KD-45 |
- |
125.0 |
350.0 |
30 |
45 |
90 |
318 |
102.5 |
113 |
51 |
- |
- |
11.00 |
| KD-50 |
- |
180.0 |
490.0 |
30 |
50 |
100 |
354 |
114.0 |
126 |
59 |
- |
- |
16.50 |
| KD-60 |
- |
280.0 |
650.0 |
30 |
60 |
120 |
408 |
135.0 |
138 |
70 |
- |
- |
25.00 |
| KD-70 |
- |
450.0 |
1200.0 |
30 |
70 |
135 |
510 |
160.0 |
190 |
92 |
- |
- |
38.00 |
| KD-80 |
- |
550.0 |
1400.0 |
30 |
80 |
160 |
560 |
180.0 |
200 |
110 |
- |
- |
55.00 |
| KD-100 |
- |
650.0 |
1900.0 |
30 |
100 |
175 |
790 |
250.0 |
290 |
135 |
- |
- |
100.00 |
|
| |
 |
| |
 |
|
|
|
| |
|
|
