| 단위 UNIT : m/m |
기호
SPECIF
형식
MODEL |
Ma
(kgf-m) |
M
(fgf-m) |
β(˚) |
dØH7 |
DØ |
L |
L1 |
C |
ℓ |
AxBJS9 |
M |
(g) |
| LD-6 |
- |
0.8 |
1.6 |
30 |
6 |
12 |
75 |
25 |
25 |
18.5 |
- |
- |
0.045 |
| LD-8 |
- |
1.5 |
3.2 |
30 |
8 |
16 |
86 |
28 |
30 |
19 |
- |
- |
0.090 |
| LD-10 |
LD-10KT |
3.0 |
7.5 |
30 |
10 |
20 |
102 |
34 |
34 |
24 |
3×11.8 |
M5 |
0.160 |
| LD-12 |
LD-12KT |
4.5 |
12.0 |
30 |
12 |
24 |
125 |
42 |
41 |
29 |
4×13.8 |
M5 |
0.300 |
| LD-14 |
LD-14KT |
7.0 |
17.0 |
30 |
14 |
28 |
143 |
47 |
49 |
32 |
5×16.3 |
M6 |
0.500 |
| LD-16 |
LD-16KT |
10.0 |
25.0 |
30 |
16 |
32 |
158 |
52 |
54 |
35 |
5×18.3 |
M6 |
0.650 |
| LD-18 |
LD-18KT |
13.0 |
32.0 |
30 |
18 |
36 |
180 |
60 |
60 |
39 |
6×20.8 |
M6 |
0.950 |
| LD-20 |
LD-20KT |
18.0 |
45.0 |
30 |
20 |
40 |
188 |
62 |
64 |
40 |
6×22.8 |
M6 |
1.200 |
| LD-22 |
LD-22KT |
24.0 |
60.0 |
30 |
22 |
44 |
200 |
65 |
70 |
42 |
6×24.8 |
M6 |
1.500 |
| LD-25 |
LD-25KT |
30.0 |
80.0 |
30 |
25 |
50 |
220 |
70 |
80 |
43 |
8×28.3 |
M8 |
2.200 |
| LD-30 |
LD-30KT |
45.0 |
115.0 |
30 |
30 |
60 |
275 |
89 |
97 |
54 |
8×33.3 |
M8 |
4.000 |
| LD-35 |
LD-35KT |
55.0 |
180.0 |
30 |
35 |
70 |
310 |
100 |
110 |
58 |
10×38.3 |
M8 |
6.050 |
| LD-40 |
LD-40KT |
85.0 |
250.0 |
30 |
40 |
80 |
350 |
114 |
112 |
67 |
12×43.3 |
M10 |
9.500 |
| LD-45 |
- |
125.0 |
350.0 |
30 |
45 |
90 |
390 |
125 |
140 |
74 |
- |
- |
12.000 |
| LD-50 |
- |
180.0 |
490.0 |
30 |
50 |
100 |
426 |
135 |
156 |
80 |
- |
- |
17.600 |
| LD-60 |
- |
280.0 |
650.0 |
30 |
60 |
120 |
485 |
150 |
185 |
80 |
- |
- |
30.000 |
|
| |
 |
| |
 |
|
|
|
| |
|
|
