| 형번 |
Dimension
& Specification |
| d(mm) |
D(mm) |
B(mm) |
L(mm) |
M(mm) |
Ts(mm) |
T
(Nm) |
F
(KN) |
P(N/mm2) |
P1(N/mm2) |
| 1947 |
19 |
47 |
20 |
26 |
6 |
15 |
260 |
26.8 |
220 |
93 |
| 2047 |
20 |
47 |
20 |
26 |
6 |
15 |
268 |
26.8 |
220 |
93 |
| 2247 |
22 |
47 |
20 |
26 |
6 |
15 |
283 |
26.8 |
207 |
96 |
| 2450 |
24 |
50 |
20 |
26 |
6 |
15 |
361 |
30.1 |
216 |
103 |
| 2550 |
25 |
50 |
20 |
26 |
6 |
15 |
376 |
30.1 |
206 |
103 |
| 2855 |
28 |
55 |
20 |
26 |
6 |
15 |
420 |
33.5 |
204 |
103 |
| 3055 |
30 |
55 |
20 |
26 |
6 |
15 |
450 |
33.5 |
190 |
103 |
| 3260 |
32 |
60 |
20 |
26 |
6 |
15 |
643 |
40.2 |
196 |
114 |
| 3560 |
35 |
60 |
20 |
26 |
6 |
15 |
703 |
40.2 |
196 |
114 |
| 3865 |
38 |
65 |
20 |
26 |
6 |
15 |
891 |
46.9 |
204 |
122 |
| 4056 |
40 |
65 |
20 |
26 |
6 |
15 |
938 |
46.9 |
200 |
123 |
| 4275 |
42 |
75 |
24 |
32 |
8 |
38 |
1537 |
73.2 |
252 |
140 |
| 4575 |
45 |
75 |
24 |
32 |
8 |
38 |
1647 |
73.2 |
236 |
141 |
| 4880 |
48 |
80 |
24 |
32 |
8 |
38 |
1756 |
73.2 |
221 |
132 |
| 5080 |
50 |
80 |
24 |
32 |
8 |
38 |
1830 |
73.2 |
212 |
132 |
| 5585 |
55 |
85 |
24 |
32 |
8 |
38 |
2348 |
85.4 |
225 |
145 |
| 6090 |
60 |
90 |
24 |
32 |
8 |
38 |
2560 |
85.4 |
206 |
137 |
| 6595 |
65 |
95 |
24 |
32 |
8 |
38 |
3170 |
97.6 |
217 |
148 |
| 70110 |
70 |
110 |
28 |
38 |
10 |
75 |
4700 |
134.4 |
231 |
147 |
| 75115 |
75 |
115 |
28 |
38 |
10 |
75 |
5000 |
134.4 |
216 |
140 |
| 80120 |
80 |
120 |
28 |
38 |
10 |
75 |
5300 |
134.4 |
202 |
134 |
| 85125 |
85 |
125 |
28 |
38 |
10 |
75 |
6500 |
153.6 |
218 |
148 |
| 90130 |
95 |
130 |
28 |
38 |
10 |
75 |
6900 |
153.6 |
205 |
141 |
| 95135 |
95 |
135 |
28 |
38 |
10 |
75 |
8200 |
172.8 |
219 |
154 |
| 100145 |
100 |
145 |
33 |
45 |
12 |
130 |
9870 |
197.4 |
219 |
151 |
| 110155 |
110 |
155 |
33 |
45 |
12 |
130 |
10800 |
187.4 |
200 |
141 |
| 120165 |
120 |
165 |
33 |
45 |
12 |
130 |
13500 |
225.6 |
209 |
152 |
| 130180 |
130 |
180 |
40 |
50 |
12 |
130 |
18300 |
282.0 |
184 |
132 |
| 140190 |
140 |
190 |
40 |
50 |
12 |
130 |
21700 |
310.1 |
188 |
138 |
| 150200 |
150 |
200 |
40 |
50 |
12 |
130 |
25300 |
338.4 |
220 |
165 |
| 160210 |
160 |
210 |
40 |
50 |
12 |
130 |
29300 |
366.6 |
195 |
148 |
| 170225 |
170 |
225 |
44 |
58 |
14 |
207 |
33000 |
389.0 |
174 |
131 |
| 180235 |
180 |
235 |
44 |
58 |
14 |
207 |
38000 |
424.0 |
179 |
137 |
| 190250 |
190 |
250 |
52 |
66 |
14 |
207 |
47000 |
495.0 |
164 |
124 |
| 200260 |
200 |
260 |
52 |
66 |
14 |
207 |
53000 |
531.0 |
167 |
128 |
|
| |
 |
| |
 |
|
|
|
| |
|
|
