Size
No.
Allowable Torque(kgf.m) Maximum
Allowable
Radial
Load
(1)
Maximum
Speed
(r.p.m)
Weight
W
(kg)
No.
Radial
Load
1/3
Radial
Load
2/3
Radial
Load
Maximum
Radial
Load
05
10
15
20
25
30
35
40
45
3.4
9.2
18
25
43
79
130
210
340
1.5
4.1
8.1
11.3
19.3
35.5
58.5
94.5
153.0
1.2
3.2
6.3
8.7
16.0
27.6
45.5
73.4
119.0
0.8
2.3
4.5
6.0
11.0
20.0
32.5
52.5
85.0
15
25
56
83
120
180
270
380
450
47,000
39,000
34,000
30,000
25,000
22,000
19,000
16,000
15,000
0.6
1.1
1.7
2.5
4.3
6.9
11.3
16.7
22.7

Size
No.
GD2
(kgf.cm3)
A
(mm)
B
(mm)
Rough
Bore
size
(mm)
Emax
(mm
F
(mm
G
(mm
H
(mm
J
(mm
05
10
15
20
25
30
35
40
45
8
24
48
80
224
440
1080
2080
3520
67
81
93
104
126
143
168
194
214
56.1
56.6
66.4
792
93.7
107.7
130.8
145
173.6
8
10
10
10
16
16
25
25
45
23
32
35
42
50
58
74
83
95
25
25
29
34
41
48
57
64
76
6.1
6.6
8.4
11.2
11.7
11.7
16.8
17.0
21.6
33
46
51
61
71
84
106
119
137
15
16
25
20
25
28
24
30
22
